Motion Simulator Series
high precision, modular design, fully integrated electronics
Motion simulators are high-precision test systems used for the calibration and characterization of inertial sensors such as accelerometers, gyroscopes, and inertial measurement units (IMUs). By generating reproducible rotational and motion profiles, they enable the accurate determination of sensor parameters and measurement deviations.
Applications
calibration & characterization of inertial sensors, alignment of optical sensors...
Modularity
Our unique modular concept enables us to offer a broad range of configurations, all built on mature and trusted technology.
These configurations range from compact single‑axis systems to high‑dynamic three‑axis solutions with integrated temperature simulation.
The flexibility of our modular design also allows us to create custom solutions that meet unique application needs without sacrificing performance.
General Specs
-
One, two or three axis configuration
-
position accuracy and repeatability down to 1 arcsec PP
-
Rate stability below 1ppm over 360 degree
-
Temperature ranges down to -55 and up to 150°C
-
Different temperature control options
Industries
aerospace, defense, automotive, directional drilling...
Key Features
-
High position accuracy & repeatability
-
High rate accuracy & stability
-
Customizable payload interface
-
Customizable slipring configuration
-
Fully integrated electronics. No external power cabinet needed.
